SOLAR PANEL - 200W, 12V Portable Folding Solar Kit With Dual Charge Feature

Description

The 200W Portable Folding Solar Kit is comprised of 2x 100W solar cells configured in parallel.The kit includes 2 x 5m extension leads, & 2 x 500mm connector lead to alligator clamps for simple connection to power. The kit includes a 15Amp, 12V Dual Charging PWM solar charge controller – allowing the user to charge two 12V batteries simultaneously.

Kit Includes
10M Accessory Lead with 50Amp Heavy Duty Connector with In-built Voltmeter
500mm Accessory Lead with Positive / Negative Battery Clamps
500mm Accessory Lead with 8mm Ring Terminals
Innovative design, sturdy support frame with cross bars
Controller is mounted to the panel leg supports, reducing de-rating
Protective abs corners, with 2 spare corner protectors included
2 x Heavy duty swivel carry handles on adjacent sides
Heavy duty carry & storage bag with accessory storage compartments

Features:
Powerful 200W 12V portable ‘brief case’ style kit
15 Amp 12V PWM dual solar charge controller for charging two 12V batteries simultaneously
Solar charge controller IP rating (IP65)
Solar controller is compatible with gel, wet, AGM, calcium & lithium batteries
Controller features reverse polarity, short circuit and over voltage protection
2 x 5m, 50A, 12-48V connector extension leads for simple connection to power
2 x 0.5m, 50A, 12-48V connector lead to positive & negative alligator clamps
Sturdy aluminium leg supports
Quality stainless steel latches and hinges
Controller securely mounted to the panel supports, reducing de-rating
Protective ABS corners
Heavy duty swivel carry handle
Heavy duty storage bag

Specifications:
Power Tolerance +3%
Maximum Power (Pmax) 200Wp
Maximum Power Voltage (Vmp) 19.6V
Maximum Power Current (Imp) 10.20A
Rated Voltage 12V
Open Circuit Voltage (Voc) 23.2V
Short Circuit Current (Isc) 11.27A
Operating Temperature -40°C to +85°C
Product Application Class A
Max System Voltage 1000V DC

Dimensions & Weight:
Dimensions Folded (mm): 787 x 688 x 65
Dimensions Unfolded (mm): 1376 x 688 x 30
Weight: 11.80kg
